| Size Id×Layer NO. | Inside Diameter mm | Tolerance mm | Reinforcement Diameter mm | Outside Diameter mm | Tolerance mm | Working Pressure MPa | Proof Pressure MPa | Burst Pressure MPa | Min Bend Radius mm | Weignht kg/m | |
| Size | Tolerance | ||||||||||
| 152*2SP | 152 | 2.0 | 173 | 3.0 | 179 | 4.0 | 15 | 30 | 37.5 | 2280 | 18 |
| 203*2SP | 203 | 2.0 | 223 | 3.0 | 230 | 4.0 | 15 | 30 | 37.5 | 3050 | 24 |
| 254*2SP | 254 | 2.0 | 275 | 3.0 | 282 | 4.0 | 10 | 20 | 25 | 3810 | 30 |
| 305*2SP | 305 | 2.0 | 330 | 3.0 | 338 | 4.0 | 8 | 16 | 24 | 4510 | 36 |
| 152*4SP | 152 | 2.0 | 184 | 3.0 | 192 | 4.0 | 25 | 50 | 62.5 | 2580 | 24 |
| 203*4SP | 203 | 2.0 | 236 | 3.0 | 243 | 4.0 | 20 | 40 | 50 | 3350 | 31 |
| 254*4SP | 254 | 2.0 | 285 | 3.0 | 292 | 4.0 | 16 | 32 | 48 | 4110 | 39 |
| 305*4SP | 305 | 2.0 | 341 | 3.0 | 350 | 4.0 | 16 | 32 | 48 | 4810 | 47 |
